DK2 4.5' × 7.5' Utility Trailer with Drive-Up Gate (MMT5X7-DUG)

1,624 lb. Payload Capacity • Drive-Up Ramp Gate • Two-Position Dump Bed • Powder-Coated Steel

Handle landscaping equipment, recreational gear, building materials, and general hauling jobs with the DK2 by Marlon MMT5X7-DUG Single-Axle Multi-Utility Trailer. Its fully welded tubular-steel frame, reinforced corrugated-steel floor, removable panels, and load-bearing gates provide a versatile hauling platform for home, farm, and property-maintenance applications.

The trailer has an 88-inch × 52-inch cargo bed and a rated 1,624 lb. payload capacity. A 40-inch rear drive-up gate functions as a loading ramp for compatible wheeled equipment, while the 24-inch front gate can be lowered or removed to accommodate longer cargo.

Key Features & Benefits

• 1,624 lb. Payload Capacity
  Provides the capacity needed to transport equipment, materials, supplies, and recreational gear within the trailer’s ratings.
• Fully Welded Tubular-Steel Frame
  Heavy-duty steel construction provides a strong foundation for demanding hauling tasks.
• UV-Resistant Powder-Coated Finish
  The black powder-coated finish helps protect the steel exterior from normal weather exposure and wear.
• 40" Rear Drive-Up Gate
  Expanded-mesh and tubular-steel gate functions as a ramp for loading compatible mowers, ATVs, carts, and other wheeled equipment.
• 24" Load-Bearing Front Gate
  Corrugated reinforced-steel front gate can support properly secured extended cargo.
• Removable Panels and Gates
  Both side panels and the front and rear gates can be removed to accommodate oversized or irregularly shaped loads.
• Two-Position Dump Bed
  Axle-mounted tilt mechanism and quick-release lock pin help simplify loading and unloading.
• Reinforced Corrugated-Steel Floor
  Provides a durable all-steel cargo surface with a published floor height of 20 inches.
• Cambered Steel Axle
  Solid square-tubular axle supports stable towing and proper trailer tracking.
• D.O.T. 5.30-12 Tires
  Bias-ply trailer tires use a common 5-on-4.5-inch wheel bolt pattern.
• D.O.T. LED Lighting
  Prewired quick-connect lights include side markers and heavy-duty taillight protectors.
• A-Frame Tow Bar
  Reinforced tongue includes a 2-inch ball coupler and a published 16-inch hitch height.
• Registration Documentation Included
  Supplied with the appropriate manufacturer paperwork for registration with the local motor vehicle agency.

Versatile Drive-Up Gate

The 40-inch rear gate provides an integrated loading ramp for compatible wheeled cargo. Its expanded-mesh surface offers traction while the tubular-steel structure provides support during loading.

This configuration is useful for transporting:

• Lawn tractors and riding mowers
• ATVs and recreational equipment
• Landscaping machines
• Garden carts and wheelbarrows
• Pressure washers and generators
• Building and property-maintenance supplies

Always verify that the equipment being loaded fits within the trailer’s dimensions and remains within its payload and GVWR limits.

Tilt and Dump Capability

The trailer bed pivots on the axle and offers two operating positions. A quick-release lock pin secures the bed during transport and allows the trailer to tilt when loading or unloading.

The tilt feature can reduce the loading angle and make it easier to unload loose or bulky materials. Cargo should remain properly balanced and secured whenever the trailer is moved.

Quick Specifications

The specifications above are based on DK2’s published product information for the MMT5X7-DUG.

Important Towing Information

The trailer uses a 2-inch ball coupler and has a published 2,090 lb. GVWR. Confirm that the tow vehicle, hitch receiver, hitch ball, wiring connection, and safety equipment are properly rated and compatible before towing.

DK2 states that its trailers are approved for highway speed limits in North America. Registration, inspection, lighting, insurance, and towing requirements may vary by state or locality, so the owner is responsible for meeting all applicable regulations.

Maintenance and Storage

DK2 recommends checking the wheel bearings before initial road use and greasing trailer bearings approximately every 2,000 miles, with more frequent service under heavy or full-capacity use. The manufacturer also recommends checking the wheel lugs and torquing them to 80 ft.-lbs.

Because this model is powder-coated steel rather than galvanized steel, scratches that expose bare metal should be cleaned and protected promptly to reduce the risk of corrosion.

Key downloads

• Product Warranty
• Product Manual
• Product Specifications Sheet

See this in action

Disclaimer: Product features vary over time so be sure to read the entire product description to verify the features of this product and what it includes at this time.
