Iron and Oak 20 Ton 3 Point Tractor Log Splitter (TMH16HYD)

Save 3%
Original price $1,699.99
Current price $1,649.99

-- OR --

Product Description

Limited Time Free Shipping

These commercial grade 3-point tractor mounted log splitters are designed for heavy duty tough applications. The powder coated finish provides longer lasting protection. Iron & Oak's rigid quality control and component testing has helped for years of productive, reliable products and service. Since 1982, the name Iron & Oak has stood for quality control and reliability when it comes to log splitters and firewood processing products.

This 3 point wood splitter is fully adjustable for any size tractor. Working height is from waist level and can be lowered right to the ground if desired to roll logs up on the beam. Only Splitter on the market with this kind of adjust-ability. This design eliminates the need for a horizontal vertical configuration, saving you time and effort.

We recommend your flow rate be a minimum of 8GPM. This will put your cycle time in the 18-19 second range. If you dont mind the split time to be a litter higher then you can go as low as 7GPM, however it will raise your cycle time up to around 25 seconds. 10GPM would be around 14 seconds. Exact tonnage will depend on your tractors output.

If your tractor is not properly equipped you do have a choice to run the PTO kit which is self contained and includes a PTO pump. Please see options.

This log splitter is fully customizable with the following optional accessories:

  • PTO Kit - PTO (Power Take Off) kit runs completely off your PTO on your tractor. There is no need to worry about any of your hydraulics as this system is self contained which includes a tank and a PTO pump. Hook up the pump to the PTO, fill the tank with fluids and your ready to split wood. This PTO pump is designed for 540RPM at the PTO for maximum speed and efficiency.
  • 4 Way Wedge - This 4 way wedge is extremely heavy duty and measures 20 inches wide. A very well thought out design allows you to slide the 4 way wedge on and off with in seconds. The 4 way wedge sits on it's own post behind the existing single wedge and includes two spacers for height adjustment. Split one log once instead of 3 times!
  • Log Tables / Cradles - Adjustable tables are great for piling up extra wood and logs to work with.

Please note: Pictures show splitter with optional accessories above. They are not included unless you purchase them. If you are unsure please contact us.

*Tonnage ratings are rated at "maximum potential" which is around 20 tons. Actual PSI of your tractor and other things such as environmental conditions can impact actual tonnage.

See options above the big red "add to cart" button for pricing and pictures. As you select them it will built and price your splitter as you go! Questions? Feel free to contact us at 888-706-2434 for no hassle no pressure help and advice. We are here to help.

Please note these log splitters are delivered via freight truck. You will be responsible to take the crate off the back of the truck unless you select lift gate delivery as an option. Some assembly is required.

Detailed Specifications

20 Ton (40,000lbs) Depending on tractor
Heavy-duty 6" H Beam
9" high carbon steel
Cylinder Stroke:
24 Inches
Log Opening:
25 Inch maximum
Cycle Time:
Depends on your tractor / PTO is 14 seconds
Operating Position:
Working Height:
Adjustable from ground to waist level
Cylinder Size:
4" x 24" Clevis type cylinder welded body 1.75" rod
Hydraulic Tank (PTO Units):
8 Gallon Tank
Hydraulic Capacity:
9.5 gallons (including tank, cylinder, hoses)
Safety Control Valve:
Detent - Auto return
400 lbs
Made in USA:
Consumer Warranty:
2 Years
Commercial Warranty:
2 Year Limited
4 Way Wedge:
Log Tables / Cradles:
Hoses & Connectors:
No - Not included
PTO Kit:
Optional - Tank, hoses & PTO pump included
